Allen Bradley AC Drive 25A-D030N104


  •  In Stock!

  • NEW (Factory Sealed)
  • Comes with the interface module standard.
  • Manufacturer: Allen Bradley – Drives
  • Product Type: AC Drive
  • Part Number: 25A-D030N104
  • Series: PowerFlex 523
  • UPC: 00885630952437
SKU: 25A-D030N104 Category:


This Allen Bradley 25A-D030N104 is a PowerFlex 523 ac drive. This AC drive operates in 3 phases, with a voltage range of 380 to 480 volts of alternating current (AC). The rated output voltage of this device is 0 to 460 volts of alternating current (AC). This device’s current is rated at 30 amperes, and the output power supplied during heavy duty is 15 horsepower or 11 kilowatts. In contrast, the rated power output is 20 horsepower or 15 kilowatts during normal duty.

Here are the technical specifications for the Allen-Bradley PowerFlex 523 25A-D030N104 AC drive:

  • Power Rating: 11 kW (15 hp)-(Heavy-duty); 15kW (20 hp)-(Normal-duty)
  • Voltage Rating: 480 VAC, 3 Phase
  • Input Voltage: 323-528V, 3 Phase
  • Output Current: 30 Amps
  • Interface Module: Standard
  • Protection Rating: IP20 NEMA / Open Type
  • Frame: Size D
  • EMC Filtering Options: No Filter
  • Weight: 4.21 kg (9.3 lbs)

In order to offer support to the drive, it is panel mounted.

The drive consists of an integrated I/O module, five discrete inputs, a single form C contact discrete output, a single analog output, and a single analog input.

The enclosure offers the handler protection against shock as a result of touch. According to NEMA, the ratings of the enclosure are IP20/ UL open type. It is important to note that the drive should not be subjected to a corrosive or volatile atmosphere, dust, or vapor whether in its operational state or in storage as the enclosure does not inhibit entry of hazardous environmental factors that may lead to damage of the internal components.

The drive features Safe-Torque Off functionality. When in storage, the AC drive should be exposed to a temperature between -40 to 85 degrees Celsius. It can withstand a relative humidity of up to 95 percent, which is non-condensing.
