Allen Bradley PLC 2080-LC30-16QWB


  •  In Stock!

  • Manufacturer: Allen Bradley – PLC
  • Product Type: PLC/Programmable Logic Controller
  • Part Number: 2080-LC30-16QWB
  • Series: Micro 830
  • UPC: 10885630058211
SKU: 2080-LC30-16QWB Category:


Designed for standalone machine control applications, Allen-Bradly® Bulletin 2080 Micro830® programmable logic controller systems accommodate flexible communication and I/O capabilities. 2080-LC30-16QWB is a Micro830 16 I/O controller.

Allen-Bradley Micro 830 Controllers 2080-LC30-16QWB Technical Specifications:

  • Digital Input Type: 10-24V DC/AC
  • Input Channels: 10 (Discrete Inputs)
  • Output Channels: 6 (Relay Output)
  • Conformally Coated: No
  • Enclosure: Meets IP20 (Which might not be ideal for outdoor use)
  • Terminal Block: Removable Terminal Block
  • Plug-In Slots: 2

This Micro 830 Controller is an Embedded Ethernet Port and RS-232/485 non-isolated Serial port, Embedded RTC, MicroSD Card support, and 2 Plug-In slots, with RTB terminals.

Available in a Base unit for 24V DC/V AC Input Type, however the High Speed Counter Support option is available as a Plug-in module.

This controller comes in a compact form and supports Din rail and panel mounting.

Two (2) plug-in modules may be added to this controller to further enhance the controller’s capability. A multitude of plug-in modules is supported by this controller particularly Discrete I/O modules, Analog I/O modules, and specialty and communication modules.

Applicable programming language includes ladder Diagram (LD), Function Block Diagram (FBD), and Structured Text. Up to 4K steps or instructions can be downloaded to this controller. This controller has 8K bytes of memory and is capable of implementing floating-point math, PID loop control, and motion control.

This controller carries certification from c-UL-us CL1DIV2, CE, C-Tick, and KC and is operable at a temperature range of -20 to 65 degrees Celsius.

Using any standard printer cable, this module’s USB 2. The 2080-LC30-16QWB is suitable for small applications and OEM machine builders, as it provides a flexible control solution at a competitively low price.


We have more than listed in stock, send us a message if you need better price or more quantity, we carry 100 193 140M 140G 440R 800F 800FD 150 194e 800t 440E 440G 440N 440K 1606 700 1734 1746 1747 1756 1762 1763 1766 1769 1794 2080 2085 2711 5069 PowerFlex 4/40/400/523/525/700/753/755 etc.
