Allen Bradley HMI 2711P-T15C21D8S


  •  In Stock!

  • Has input voltage of 24V DC.
  • Features DC of power.
  • Manufacturer: Allen Bradley – HMI
  • Product Type: HMI / Operator Interface
  • Part Number: 2711P-T15C21D8S
  • Series: Panelview Plus 7
  • UPC: 887172715440
SKU: 2711P-T15C21D8S Category:


The Allen Bradley 2711P-T15C21D8S is an operator terminal from Panelview Plus 7 series terminals.

The device has a color TFT LCD touch screen, a 15-inch display size, and a 1024 x 768 pixels resolution.

This terminal uses an input power of 24V DC (direct current).

It has 512 MB RAM and 512 MB internal storage with 80 MB of free user memory. That internal storage can be increased using internal cards and external flash drives.

This standard terminal has 2 USB high-speed ports and a single Ethernet/IP port that allows for communication between a host computer and a local flash drive.

Additionally, there is one embedded 10/100Base-T, Auto MDI/MDI-X Ethernet port for network connection.

The terminal can start and perform connection to 1 controller and up to 100 screens and 500 alarms. Also, Ethernet communication can support linear and network star topology through the Ethernet port.

The 2711P-15C21D8S runs a human machine interface (HMI) with several parts. Using this terminal HMI applications, animated graphics and text displays can present every point in machine processing applications and control other devices on Ethernet/IP networks.

The ambient temperature surrounding the terminal must be kept within 0~55 °C (32~131 °F).


We have more than listed, send us a message if you need better price or more quantity, we carry 100 193 140M 140G 440R 800F 800FD 150 194e 800t 440E 440G 440N 440K 1606 700 1734 1746 1747 1756 1762 1763 1766 1769 1794 2080 2085 2711 5069 PowerFlex 4/40/400/523/525/700/753/755 etc.
