Allen Bradley HMI 2711P-B15C4D8


  •  In Stock!

  • Has dc of power.
  • Manufacturer: Allen Bradley – HMI
  • Product Type: HMI / Operator Interface
  • Part Number: 2711P-B15C4D8
  • Series: Panelview Plus 6
  • UPC: 10612598876829
SKU: 2711P-B15C4D8 Category:


The 2711P-B15C4D8 PanelView Plus 6 HMI module from Allen-Bradley allows users to interface with their equipment, is an operator terminal module.

This Panelview Plus 6 is an application that allows the user to control processes and machines. The user has control over the system by entering information and data into the keypad/touchscreen.

A DC source varies from 18 to 32 volts to power this machine.

Includes a RAM size of 512MB, as well as a storage capacity of 512 MB nonvolatile flash memory.

This item’s internal backlight substitute component number, if applicable, is 2711P-RL15C.

This connection is also capable of transferring applications and printing. The latest Ethernet/IP screen shows and enables the user to modify the Ethernet/IP connection of a PanelView terminal. If an additional Ethernet port for the 700 to 1500 terminals is needed, the 2711P-RN20 Ethernet networking facility is provided. The module is assigned its own IP address. This port supports MDI/MDI-X connectivity and is equipped with an RJ45, 10/100Base-T network connection.

The 2711P-B15C4D8 has a 15-inch active color matrix display that can be used with either a finger or a pen, with a resolution of 1024 × 768 pixels, 18-bit color graphics, and a 304 by 228-millimeter effective viewing area (12.0 x 9.0 inches). Also had a keypad, the keypad includes function keys that may be configured to save and rapidly trigger bespoke functions.

It features a CCFL backlight with a 50,000-hour life. This backlight is serviceable in the field.

This HMI’s integrated input interface consists of a 40-function keypad and an 8-wire analog resistive touchscreen. Both input ports are enabled to 1 million actuations.

This device is equipped with 1 Ethernet port, 1 serial RS-232 port, and 2 USB ports. Additionally, it has an SD card insertion port for adding removable storage through an SD card.


We have more than listed, send us a message if you need better price or more quantity, we carry 100 193 140M 140G 440R 800F 800FD 150 194e 800t 440E 440G 440N 440K 1606 700 1734 1746 1747 1756 1762 1763 1766 1769 1794 2080 2085 2711 5069 PowerFlex 4/40/400/523/525/700/753/755 etc.
