Description

The Allen-Bradley PanelView 2711P-T15C22D9P is a sophisticated user-controlled terminal used for various functions and industrial environments.
The device belongs to Rockwell Automation’s PanelView Plus 7 Performance Terminal series and is known for its excellent performance characteristics.
The operator panel can monitor and control machine components’ status in an automation system. The device’s graphic user interfaces include a highly sensitive touch screen that can initiate and trigger functions and applications within the control system. The touch screen can also be used to create applications by ensuring the alignment of the interactive touch cells with specific touch screen objects. The touch screen is analog resistive and has an actuation rating of one million presses.

The Allen-Bradley PanelView 2711P-T15C22D9P terminal is an operator panel that functions on an input power source rated at 24V of direct current. The direct current power consumption at this rated voltage is a maximum of 50 watts.

The terminal is equipped with a real-time clock backup battery with a service life of 4 years. A replacement CR2032 lithium coin cell battery can also be used as a replacement.

The device has two Ethernet ports that can be used to configure the device over an Ethernet/IP network and enable communication channels with remote I/O devices such as printers and scanners. The network can be used to relay messages, instructions, data, and feedback to and from the operator panel.

Also, the terminal can be connected to a linear or star topology network, but ring topology brings additional security when the line is broken. It has an integrated DLR (device level ring) option and 2 USB high speed ports for connecting to 1 controller (maximum).

The Allen Bradley 2711P-T15C22D9P is an operator terminal from Panelview Plus 7 series. It has a color TFT XGA LCD touch screen with a 15inch display size with a 1024 x 768pixel resolution. The display’s aspect ratio is 4:3. The touch screen is analog resistive with a backlight and has an actuation rating of 1 million presses, like all other members of Panelview Plus 7.

The 2711P-T15C22D9P has 512 MB RAM and 512 MB storage with 80 MB of user free storage. The memory can be increased by adding internal or external cards.

This terminal can also be used for HMI, or human machine interface, applications. That concept was started before Panelview Plus 6 series. Still, it was highly expanded with Panelview Plus 7, so the terminal can now perform local machine visualization and much more than that.

The input supply voltage is 18-30V DC, and the unit operating temperature is 32 ~ 131 ℉. The physical dimensions of this device measure 318 x 381 x 69.6 mm, or 12.52 x 15.00 x 2.742 inches (HxWxD). The item’s weight is approximately 3.69 kg or 8.14 lb.
