Allen Bradley HMI 2711P-T10C4D8


  •  In Stock!

  • Contains 512MB ram memory.
  • Offers power of DC.
  • Manufacturer: Allen Bradley – HMI
  • Product Type: HMI / Operator Interface
  • Part Number: 2711P-T10C4D8
  • Series: Panelview Plus 7
  • UPC: 10612598876669
SKU: 2711P-T10C4D8 Category:


The Allen-Bradley 2711P-T10C4D8 PanelView Plus 6 graphic color terminal provides a 10.4 inches active-matrix thin-film transistor (TFT) with a liquid crystal (LCD) display which has a resolution of 640 x 480 pixels, has 18-bit color graphics, operates with the touch screen.

The Allen-Bradley 2711P-T10C4D8 terminal contains two USB ports supporting keyboards, mouse devices (HID devices) and USB printers, an integral RS-232 serial electrical isolated port for uploading/downloading applications and printing and an Ethernet electrical isolated communication port.

The Allen-Bradley 2711P-T10C4D8 terminal includes 512 megabytes of random access memory (RAM) for runtime applications and 512 megabytes nonvolatile flash memory. The Allen-Bradley 2711P-T10C4D8 supports memory Type I CompactFlash cards to save and store applications.

This 2711P-T10C4D8 PanelView Plus 6- 1000 model terminal provides modular components configuration, which includes a display module with a touch screen, a logic module, ControlNet and DH+ /DH-485 communication modules.

This color terminal uses 2711-NC14, 2711-NC13 and 1585J-M type cables to communicate with PLC-5, SLC and MicroLogix controllers.

The Allen-Bradley 2711P-T10C4D8 color touchscreen terminal supports an input voltage rating range of 18-32V DC with a maximum power consumption of 70W.

The 2711P-T10C4D8 terminal is designed to meet the NEMA Type and IEC enclosure ratings. The Allen-Bradley 2711P-T10C4D8 should be installed in panels or enclosures using mounting clips to preserve the internal circuitry.

This PanelView terminal can operate at a temperature range of 0-55℃(32-131℉) for indoor and outdoor applications and weighs approximately 2.6kg (5.7lb) while shipping.

The 2711P-T10C4D8 requires a 24V DC (direct current) input to operate.


By increasing this unit’s processor speed, Allen-Bradley improved this device compared to previous iterations because it resulted in a fast and reliable operator interface.
The display module, input touch module, and logic module are this product’s three most important parts. These three parts are generally organized to do multiple things, such as upgrading, migration or being able to be interchanged with a different unit. However, it is uncommon that the complete terminal must be changed.
Embedded within this Allen-Bradley device is 1 Ethernet port, 1 RS-232 port, and 2 USB ports used primarily for communication. The RS-232 port is a serial interface usually used for programming purposes with a handheld terminal or laptop. The other two ports are used for network connection. This product can be connected to other devices when connected to a network. External devices, printers, keyboards, etc., are all examples of devices that this product can be connected to.
When this terminal is not being used, it is important to keep the surrounding temperature within -13~158℉.
