Allen-Bradley HMI 2711P-T15C22D8S


  •  In Stock!

  • Has input voltage of 24V DC.
  • Features DC of power.
  • Manufacturer: Allen Bradley – HMI
  • Product Type: HMI / Operator Interface
  • Part Number: 2711P-T15C22D8S
  • Series: Panelview Plus 7
SKU: 2711P-T15C22D8S Category:


The 2711P- T15C22D8S is a PanelView Plus 7 Standard operator terminal from Allen-Bradley. The device features a 15-inch, colored TFT LCD screen, embedded analog resistive touchscreen input, and dual Ethernet communication port.

The 2711P- T15C22D8S is a cost-effective solution for implementing real-time process and machine visualization and control in the factory-floor area of the plant. It is equipped with modern capabilities that help meet today’s plant automation and connectivity demands. This device is carries certifications from IECEx, CCC Ex, cULus, ATEX, INMETRO, CE (EMC), CE (LVD), RCM, EAC, RoHS and KCC. It is installed to an enclosure rated NEMA and UL Type 12, 13, 4X (indoor use only), also rated IP54 or IP66 as Classified by UL.

The application is downloaded and executed by the operator terminal via the pre-activated runtime environment of FTView Machine Edition.

The 2711P- T15C22D8S has embedded internal memory amounting to 512 MB Random Access Memory (RAM), 512 MB Storage and 80 MB non-volatile user memory. It also uses a CR2032 lithium coin cell battery for the Real-Time built-in clock. This battery has +/-+/-2 minutes per month accuracy and expected battery life of 4 years at 25 °C (77 °F).

The viewing area is 304 x 288 mm with 1024 x 768 XGA and 18-bit color graphics. The aspect ratio is 4:3 with a brightness of 300 nits. It has a Real-Time clock that is battery backed-up with an operating lifespan of 4 years, minimum at 25 °C. It can be replaced with a CR2032 lithium coin cell. The non-replaceable LED backlight half-life is 50,000 hours. Its touchscreen is analog resistive with a 1-million press actuation rating. The touchscreen has a 100-gram operating force.


We have more than listed, send us a message if you need better price or more quantity, we carry 100 193 140M 140G 440R 800F 800FD 150 194e 800t 440E 440G 440N 440K 1606 700 1734 1746 1747 1756 1762 1763 1766 1769 1794 2080 2085 2711 5069 PowerFlex 4/40/400/523/525/700/753/755 etc.
