Allen Bradley HMI 2711P-T10C22D9P


  •  In Stock!

  • Has 24 volts DC of input voltage.
  • Comes with DC of power.
  • Manufacturer: Allen Bradley – HMI
  • Product Type: HMI / Operator Interface
  • Part Number: 2711P-T10C22D9P
  • Series: Panelview Plus 7
  • UPC: 885630844626
SKU: 2711P-T10C22D9P Category:


The Allen-Bradley 2711P-T10C22D9P Panelview Plus 7 is the operator terminal. This module is a touchscreen performance PanelView designed to help input commands to various networks via its color TFT display with an SVGA resolution of 800 x 600 and 18-bit graphics.
It has a white-light diode, and a solid-state LED backlight with about 50,000 hours of life, and it cannot be replaced.
Also, it has a single SD card that allows for external storage because it supports and is compatible with SD cards corresponding to the number 1784-SDx.
The available memory is 1GB of RAM and 512MB for free user storage.

It comes with two 10/100 Base-T DLR Ethernet ports, a pair of Type A 2.0 USB high-speed ports, and another high-speed 2.0 device port.

The Allen-Bradley 2711P-T10C22D9P module has a nominal voltage of 24V DC, a 100 – 240V AC power rating, and a maximum power consumption of 50W. This module also supports (SELV) and (PELV) 24V DC supplies. It has a shipping weight of approximately 2.28kg or 5.03lb and dimensions of about 9.92 x 11.69 x 2.74 inches.

The display screen of the 2711P-T10C22D9P module measures 10.4 inches diagonally. Several accessories can be purchased along with this module, other protective overlays, SD (Secure Digital) cards, battery replacements, and power terminal blocks.
It also has several certifications, including but not limited to 22, ATEX Zone 2, CE (LVD), and EAC.


We have more than listed, send us a message if you need better price or more quantity, we carry 100 193 140M 140G 440R 800F 800FD 150 194e 800t 440E 440G 440N 440K 1606 700 1734 1746 1747 1756 1762 1763 1766 1769 1794 2080 2085 2711 5069 PowerFlex 4/40/400/523/525/700/753/755 etc.
