Allen Bradley AC Drive 22A-B017N104


  • In Stock!

  • Manufacturer: Allen Bradley – Drives
  • Product Type: AC Drive
  • Part Number: 22A-B017N104
  • Series: PowerFlex 4
  • UPC:00662453979625
SKU: 22A-B017N104 Category:


The Allen-Bradley 22A-B017N104 is a PowerFlex 4 adjustable frequency AC drive that provides a full-featured four digits alphanumeric human interface liquid crystal (LCD) display module to show either parameter number and value or fault code with an integral digital keypad to program and control employing the local potentiometer both torque and speed of three-phase induction motors in industrial applications.

  • Voltage Rating: 240 Volts AC, 3 PH
  • Power Rating: 5 HP, 3.7 KW
  • Output Current: 17.5 Amperes
  • Enclosure Panel: IP 20 (NEMA Type Open)
  • Frame: B
  • Human Interface Module: Fixed Keypad
  • Emission Class: Not Filtered
  • Brake IGBT: Yes
  • Communication Port: RS-485
  • Fuses: 35
  • Weight: 1.81 Kg (3.99 pounds)

It takes input voltage rating of 200 to 240 VAC, three-phase, and converts it to an output voltage within the range of 0 to 230 VAC, three-phase, with a continuous current of 17.5 amperes. The output frequency is programmable from 0 to 240 Hz. It has input ratings of 8.6 kVA and 21.0 Amps.

The 22A-B017N104 provides various protective features including overload, overcurrent, overvoltage, undervoltage, control ride through, and faultless power ride through protections. At start up, this drive can overcome startup torque, mainly using its capability of providing 150% overload for up to 1 minute or 200% overload capability for up to 3 seconds. The motor is protected using the drive electronic overload.

The 22A-B017N104 can be mounted with an input circuit breaker or fuses. This variable frequency controller produces torque efficiently over a large speed range and offers sensorless vector control. The device supports shielded and unshielded cables for wiring and installation. The control parameters have to be adjusted locally or remotely after installation. It can be set manually or by using compatible handheld programmable devices.

The VFD provides removable MOV to ground ungrounded distribution systems to increase motor life. This drive includes relay pre-charge to limit inrush current.

Locally, the supplied fixed digital keypad (IP20 protected) and LED display can be used to program various parameters. Operators are able to program preset frequencies, acceleration and deceleration times, configuration of input control lines, and more. This unit can accelerate and decelerate from 0 to 600 seconds, programmable in 0.1 second increments.

The 22A-B017N104 is capable of being integrated with control systems such as CompactLogix or ControlLogix controllers via the integrated RS485 communication port.
Aside from integration via communication protocol, the 22A-B017N104 also supports traditional integration via hardwiring of external devices to the drive’s built-in 3 fixed for START/STOP/REV discrete inputs, 2 fully programmable discrete outputs, 1 analog input that supports 0-10V or 4-20 mA)

The 22A-B017N104 includes ten (10) LED indicators that report and display visual notification of drive status and information.

This device supports the RS-485 (DSI) protocol to communicate with Rockwell Automation devices and to be programmed by a PC.

The 22A-B017N104 is conceived to meet the IP20 and NEMA Type open enclosure ratings.

This unit can be installed vertically on a 35-millimeter DIN on B frame drives or using M4 screws.

This VFD offers an adjustable pulse width modulation (PWM) frequency of up to 16 kHz to ensure proper operation.

The 22A-B017N104 can operate at a temperature range of 10 to 50 degrees Celsius (14 to 122 degrees Fahrenheit) for industrial applications from fans to extruders and weighs approximately 1.81 Kilograms (3.99 pounds) while shipping.

Additional information

Weight 2.39 kg
