Description

Part number 1734-ADN is a point input / output DeviceNet adapter. This device is primarily used to implement distributed I/O systems to industrial applications. This Allen-Bradley product supports DIN rail mounting. The nominal input rating of this device is twenty-four (24) volts direct current (DC). The DeviceNet input voltage range is from eleven (11) to twenty-five (25) volts direct current (DC). This unit is reverse polarity protected when it comes to its input overvoltage protection. Additionally, the DeviceNet power requirements of this unit are twenty-four (24) volts DC at thirty (30) milliamperes maximum.

The Allen-Bradley 1734-ADN has a rated input voltage of twenty-four volts direct current nominal, with a range of ten (10) to twenty-eight-point-eight (28.8) volts DC. The field side power requirements of this device is twenty-four (24) volts DC at four hundred (400) milliamperes maximum. The maximum inrush current of this product is six (6) amperes for ten (10) milliseceonds. This Allen-Bradley product is equipped with three (3) red and green status indicators and two (2) power supply status indicators that light up green. This unit’s power consumption is 8.1 watts (W) at 28.8 volts DC and its power dissipation at maximum is 2.8 watts at 28.8 volts. Additionally, 9.5 BTU/hr at 28.8 volts DC is this device’s maximum thermal dissipation.

The dimensions of this Allen-Bradley point I/O DeviceNet adapter measure out to 76.2 mm x 54.9 mm x 133.4 mm, or the equivalent of 3.0 inches x 2.16 inches x 5.25 inches. The weight of this product comes in at approximately 260 grams, or 9.17 ounces.
