The Allen Bradley 25B-D6P0N104 is a PowerFlex 525 series AC drive manufactured by Rockwell Automation. It is a variable frequency drive that controls three-phase induction motors with Embedded EtherNet/IP and Safety.
Here are some of the technical specifications of the Allen Bradley AC drive 25B-D6P0N104:
- Output Power Rating: 2.2 kW (3 hp) (Normal and Heavy-duty)
- Output Voltage Rating: 480 VAC, 3 Phase
- Output Current: 6 Amps
- Input Voltage: 323-528V, 3 Phase
- Interface Module: Standard
- Protection Rating: IP20 NEMA / Open Type
- Frame: Size A
- EMC Filtering Options: No Filter
- Ambient Temperature: -20°C to 50°C (-4°F to 122°F)
- Dimensions: 152 x 72 x 172 mm
- Weight: 1.4 kg (3.0 lb)
The Allen-Bradley 25B-D6P0N104 PowerFlex alternating current drive that can be used in conjunction with a motor for speed control applications. The user can use the alternating current drive to modulate the frequency of the input signal transmitted to the motor. This modulation causes changes in the electromagnetic field surrounding the rotating components of the motor. It allows the user to control the number of revolutions traversed by the motor per minute.
An isolated gate bipolar transistor is used to optimize the productivity of the drive and ensure that the user can effectively use the device in industrial automation systems. A brake is also provided within the drive to enhance the driver’s ability to control the motor’s speed.
The alternating current drive can also be used for complex torque control applications in mechanical systems like pumps and compressors.
The device is primarily housed in a NEMA-rated enclosure and must be installed to ensure accessibility and ease of maintenance and replacement.
Accessory cards are supported with this device, and up to two (2) cards can be used at a time.
The 25B-D6P0N104 interacts through an embedded Ethernet/IP port, allowing control of the Ethernet network and an inbuilt RS-485 serial interface, allowing for a multi-drop communication setup.
The PowerFLex 520 series drives incorporate a detachable control module and power module, allowing for simultaneous configuration and installation, and a common control module is utilized throughout the entire power range.
This drive includes built-in safety measures such as automated BUS voltage management and fast-acting current limiting, as well as a Safe Torque-Off function that is shared by all PowerFlex 525 drives. With the MainsFree setup, you may connect your control module to a PC using a regular USB cable and instantly upload, download, and flash the drive with new settings.
The drive is equipped with sophisticated circuit breakers to protect the device and its surrounding components from sudden spikes in voltage.
