Allen Bradley Expansion Output Modules 2085-OB16


  •  In Stock!

  • 2080 Micro800 System.
  • Has 12/24v dc, sink/source input type.
  • Manufacturer: Allen Bradley – Drives
  • Product Type: Drive
  • Part Number: 2085-OB16
  • Series: Micro 850
  • UPC: 10885630082315
SKU: 2085-OB16 Category:


The Micro800™ expansion I/O is a modular I/O that complements and extends the capabilities of Micro850™ controllers. These expansion I/O modules interfaces with Micro850 controllers using an I/O expansion port.

They come with 16 LED status indicators and a removable terminal block (RTB). It is important that the 2085-IQ16 module be removed or inserted only when the backplane power is turned off to avoid an electrical arc that can result in an explosion. This module is also sensitive to electrostatic discharge or ESD.

The following is the data for the 2085-IQ16:

  • Input Channels: 16
  • Input Type: Digital
  • Input Voltage Range: 12/24VDC source voltage
  • Operating Temperature: 0 to 60 °C (32 to 140 °F)
  • Storage Temperature: -40 to 85 °C (-40 to 185 °F)
  • Humidity: 5 to 95% non-condensing
  • Mounting: DIN rail or panel mount
  • Dimensions: 100 mm x 90 mm x 30 mm (3.94 in x 3.54 in x 1.18 in)
  • IEC compliant.
  • LED indication for input status.
  • Screw terminal block for easy wiring.
  • Multiple modules can be connected together to increase input points.

It is important to note that the 2085-IQ16 module must be properly installed, configured, and maintained to ensure reliable and safe operation in your specific application.

The 2085-OB16 has a maximum power dissipation of 5W when operational and it has a T4 (North America) designated temperature code. It provides 50V (continuous) isolation voltage between the channel and the system type, using the Reinforced Insulation Type tested at 720V AC for the 60s.
