Allen Bradley Analog Output Module 5069-OF8


  • In Stock!

  • Manufacturer: Allen Bradley – Miscellaneous
  • Product Type: Analog Output Module
  • Part Number: 5069-OF8
  • Series: CompactLogix 5069
  • UPC: 885630530116
SKU: 5069-OF8 Category:


The Allen-Bradley 5069-OF8 is an analog input module that is included in the Compact 5000 I/O series. It supports voltage and current outputs. It comes in an open-style enclosure and occupies one slot in the chassis. This module has eight output channels. It can detect currents up to 20 milliamperes and voltages of up to 10 volts. It consumes 5.3 watts of power and has a thermal dissipation rating of 18.1 BTU per hour.

  • Module Type: Analog output module
  • MOD Power Passthrough, max: 9.55 A @ 18…32V DC
  • Open circuit detection: Current mode only
  • Resolution: 16 bits across ± 10.5V – 320 µV/bit 16 bits across 10.5V – 160 µV/bit
  • 16 bits across 5.25V – 80 µV/bit 16 bits across 21 mA – 320 nA/bit
  • Conversion time per channel: 25 µs
  • Conversion method: R-Ladder DAC, monotonicity with no missing codes
  • Output Current signal: 0-20 mA and 4-20 mA
  • Output Voltage signal: ±10VDC; 0-10VDC; 0-5VDC
  • No. of Inputs: Eight (8) channels
  • Series: Compact 5000 I/O
  • Data format: IEEE 32-bit floating point
  • Analog output ratings: +/–10V DC, 0…20 mA per channel
  • MOD Power 75 mA: @ 18…32V DC
  • SA Power 250 mA: @ 18…32V DC
  • SA Power Passthrough, max: 9.95 A @ 18…32V DC
  • Number of Inputs: N/A
  • Number of Outputs: 8 Voltage or Current Outputs
  • Voltage Category: N/A
  • Input Voltage Range: N/A
  • Output Voltage Range: +/- 10 Volts, 0-10 Volts, 0-5 Volts
  • Power Dissipation: 5.3 Watts
  • Enclosure Type: None (Open Style)
  • Dimensions: 5.4 x 0.9 x 4.2 in (138 x 22 x 105 mm)
  • Weight: 0.39 lbs (175 g)
  • CIP Sync Supported: Yes
  • Pattern Matching Supported: Yes

This module features eight voltage or current output channels. The output range for voltage is +/- 10 volts, 0 to 10 volts, and 0 to 5 volts. The available output range for current is between 0 to 20 milliamperes and between 4 to 20 milliamperes. The module has 16 bits of data available. The resolution ranges from 80 micro-volts per bit to 320 micro-volts per bit for voltage and 320 milliamperes per bit.

The module has a drive capability of one kilo ohm minimum for voltage and 500 ohms maximum for current. Voltage mode allows the module to carry a capacitive load of up to one microfarad. Current mode gives a maximum inductive load of one millihenry. The module provides open circuit detection while in current mode. It provides short circuit detection while operating in voltage mode with the output electronically limited to 16 milliamperes or less. The output module takes just 25 microseconds to convert the input signal using an R ladder DAC. Overvoltage protection is also provided to a limit of 32 volts DC. The module occupies a slot width of one in the chassis. It has dimensions of 144.57 x 22 x 105.42 millimeters (5.69 x 0.87 x 4.15 inches). It supports mounting using a compatible zinc-plated chromate-passivated steel DIN rail. The EN50022 DIN rail is compatible with this unit. The module supports the 5069-RTB18-SPRING and -SCREW removable terminal blocks.


Additional information

Weight 0.25 kg
