Allen Bradley DC Input Module 5069-IB16F


  • In Stock!

  • Manufacturer: Allen Bradley – Miscellaneous
  • Product Type: DC Input Module
  • Part Number: 5069-IB16F
  • Series: CompactLogix 5069
  • UPC: 885630530048
SKU: 5069-IB16F Category:


The Allen-Bradley 5069-IB16F is a Digital Input Module that provides sixteen (16) sinking inputs.

  • Description: Digital Input Module
  • Number of Inputs: 16 Channels (1 group of 16), Sinking
  • Input Voltage Range: 10-32 V DC
  • Power Bus (MOD Power) Current: 75 mm
  • Sensor Actuator Power Bus (SA Power) Passthrough Voltage Ranges: 18-32 V DC
  • Sensor Actuator Power Bus (SA Power) Current Rating: 9.55 A
  • Power Dissipation: 3.9 W
  • Thermal Dissipation: 13.3 British Thermal Units (BTU) per Hour
  • Isolation Voltage: 300 V
  • Indicators: 1 green/red module status indicator and 16 yellow I/O status indicators
  • Slot Width: 1
  • Size (H x W x D): 138 x 22 x 105 mm (5.43 x 0.87 x 4.15 inches)
  • Weight: 175 g (0.39 pounds)

This module supports a sensor-actuator passthrough voltage from 18 Volts DC to 32 Volts DC. The 5069-IB16F has a red/green LED indicator that shows the module status and sixteen (16) yellow LED indicators for input channel status. The unit dissipates an electrical power of 3.9 Watts and a thermal power of 13.3 British Thermal Units (BTU) per hour. The module supports a vibration frequency range from 10 to 500 Hertz. The module has an operating specification for the mechanical shock level of 30 g. The module also has a storage specification for the mechanical shock level of 50 g.

The Allen-Bradley 5069-IB16F supports a non-condensing relative humidity range from 5% to 95%. This module can be stored in a safe environment that shouldn’t be full of condensation or corrosion at a temperature from -40 to 85 degrees Celsius (-40 to 185 degrees Fahrenheit). The 5069-IB16F has an open enclosure. The device can be easily inserted on a DIN rail. The module has dimensions of 138 millimeters (5.43 inches) in height, 22 millimeters (0.87 inches) in width, and a depth of 105 millimeters (4.15 inches). The 5069-IB16F can operate at a temperature range of zero (0) to 60 degrees Celsius (32 to 140 degrees Fahrenheit) for industrial applications and weighs approximately 175 grams (0.39 pounds) while shipping.

Additional information

Weight 0.24 kg
