Description

The Allen Bradley 22B-D4P0N104 is a compact, cost-effective AC drive designed for controlling AC induction motors. It supports an input voltage rating of 480 Volts AC and current consumption of 4 Amperes with a maximum power rating of 1.5 horsepower and 2 Kilowatts. The drive has a NEMA/UL Type Open Style Enclosure with an IP20 protection rating. It has built-in USB and RS-485 communication ports for connectivity to PLCs and other devices. The drive also features an LCD display for easy setup and operation, and supports multiple control modes including V/Hz, sensorless vector, and closed-loop vector control. The 22B-D4P0N104 is compatible with MicroLogix and CompactLogix PLCs.

The Allen Bradley Drive 22B-D4P0N104 is a PowerFlex 40 AC drive designed for the variable frequency control of AC induction motors. It features:

• Input voltage: 480VAC, 3PH
• Output current: 4.0A
• IP20 NEMA/UL Type Open Style Enclosure
• Frame Size B
• Built-in USB and RS-485 communication ports
• MicroLogix and CompactLogix compatibility
• User-friendly interface with an LCD display
• Multiple control and feedback options
• Supports multiple control modes (V/Hz, sensorless vector, and closed-loop vector).
• It does not have a filtering keypad and has a fixed keypad

***********************************

The Allen-Bradley 22B-D4P0N104 adjustable frequency AC drive provides a full-featured 4 digit alphanumeric human interface liquid crystal (LCD) display module to show either parameter number and value or fault code with an integral keypad; this is used to set and control both torque and speed of three-phase motors using the local potentiometer.

The 22B-D4P0N104 can be mounted with an input circuit breaker or fuses.

The 22B-D4P0N104 produces torque efficiently over a large speed range and offers sensorless vector control. The 22B-D4P0N104 AC drive provides removable MOV to ground ungrounded distribution systems to increase motor life. The 22B-D4P0N104 drive includes relay pre-charge to limit inrush current.

This drive contains 7 LED indicators that report and display visual notifications of drive status and other information.

The 22B-D4P0N104 supports the RS-485 (DSI) protocol to communicate with Rockwell Automation devices and to program from a PC.

The 22B-D4P0N104 AC drive is constructed to meet its IP20 and NEMA Type open enclosure ratings.

The 22B-D4P0N104 can be installed vertically on a 35-millimeter DIN on B frame drives or using M4 screws.

The 22B-D4P0N104 can function as a stand-alone controller for controlling the motor speed in processes or machines with the help of process PID capabilities which are included in the drive. This drive can be connected to a daisy-chain RS485 network in addition to the internal process PID capabilities with the help of an inbuilt RS485 communication connection. The enclosure protects the drive’s circuitry as well as the drive’s many connectors simultaneously. It may be installed and adjusted to give motor control with easy programming. Functions on the drive make the control methods easier and help you have less hardware design costs.
