Allen Bradley 32 Pt Output Module 1769-OB32

$379.00

  • In Stock!

  • Manufacturer: Allen Bradley – PLC
  • Product Type: Output Module
  • Part Number: 1769-OB32
  • Series: CompactLogix 1769
  • UPC: 10611320915669
SKU: 1769-OB32 Category:

Description

This Allen-Bradley CompactLogix is a dc output module. This part provides digital output input type. It has open enclosure type.

  • Series: 1769 compact DC solid-state output module
  • Number of digital outputs: 32 (16 points/group)
  • Operating voltage range: 20.4-26.4V DC
  • Current draw at 5.1V: 300 mA
  • Heat dissipation: 4.5 W
  • Current per module, max: 4.0 A @ 60 °C (140 °F), 8.0 A @ 30 °C (86 °F)
  • Wire size and type: 0.325… 2.080 mm2 (22…14 AWG) solid copper wire or 0.325…1.310 mm2 (22…16 AWG) stranded copper wire rated at 90 °C (194 °F ) insulation max
  • Surge current: 2 A for 10 ms
  • Operating temperature range: 0 °C…60 °C (32 °F…140 °F)
  • Dimensions (H x W x D), approx :118 x 52.5 x 87 mm (4.65 x 2.07 x 3.43 in.) Height with mounting tabs 138 mm (5.43 in.)
  • Weight: 450 g (0.992 lb)
  • Module location: DIN rail (EN 50 022 – 35 x 7.5 or EN 50 022 – 35 x 15) or panel mount
  • Power supply: 1769-PA2, 1769-PB2, 1769-PA4, 1769-PB4

The Allen-Bradley 1769-OB32 compact DC solid-state module has 32 digital outputs. The 1769-OB32 operates between 20.4 volts and 26.4 volts DC. This module can be employed by controllers such as the CompactLogix controller or the MicroLogix 1500 controller. The 1769-OB32 module can be employed in several applications mainly in the industrial field. The 1769-OB32 module can be used with a 1769-ADN DeviceNet adapter or with a 1769-AENTR Ethernet adapter.

The 1769-OB32 module can be mounted on well-grounded panels using two mounting M4 or #8 screws or on either EN 50 022 – 35 x 7.5 or EN 50 022 – 35 x 15 DIN rails. The minimum on-state current for this module is 1 milliamp and the output delay is 1 millisecond. This Allen-Bradley 1769-OB32 DC solid-state output module can be supplied through 1769 Compact I/O power supplies such as1769-PB4, 1769-PB2, 1769-PA4, 1769-PA2 power supplies except when connected to a MicroLogix 1500 base with a current consumption of 300 milliamps. The 1769-OB32 Allen-Bradley module can be connected easily to either the controller or to an adjacent I/O module before or after mounting. The surge current that the module can handle is 2 amps. The 1769-OB32 32-point module is intended for use in a mainly industrial environment that is clean and dry (Pollution degree 2) and to circuits not exceeding Over Voltage Category II (IEC 60664-1). The 1769-OB32 digital module provides two isolated groups with 16 points per group. This module weighs approximately 450 grams (0.992 pounds) while shipping. This Allen-Bradley module works properly at 0 to 60 degrees Celsius (32 to 140 degrees Fahrenheit).

Additional information

Weight 0.41 kg
