Description

The Allen-Bradley 1762-OB16 is a MicroLogix Expansion I/O module that is a part of Bulletin 1762 MicroLogix Expansion I/O Module system series. The module is extremely flexible and supports 16 output channels. These channels support source wiring configuration. This device has an operating voltage range of 20.4 to 26.4 volts DC. The operating temperature range for this product is from 0 to 55 degrees Celsius. The physical dimensions of this device measure out to 90 x 40.4 x 87 mm.

• Part Number/Catalog No. 1762-OB16
• No. of installation: Four (4) with MicroLogix 1100; Six (6) with MicroLogix 1200;
• Seven (7) with MicroLogix 1400.
• Output Groups: Group 1: Outputs 0…15
• No. of Groups: 1 groups
• No. of Inputs: 16
• Voltage Category: 24VDC
• Output Voltage Range: 20.4-26.4VDC
• Compatible Controllers: MicroLogix 1100, 1200 and 1400
• Signal delay, On: 0.1 ms
• Signal Delay, Off: 1.0 ms
• Bus current draw, max: 175 mA @ 5V DC (0.88W)
• Outputs (16) Sourcing
• Mounting DIN Rail
• Input Power 24 Volts DC
• Operating Voltage Range 20 to 26.4 Volts DC
• Maximum Surge Current 2.0 A
• Maximum Bus Current Draw 175 mA at 5 Volts DC
• Maximum Operating Altitude 2000 meters
