Description

The Allen Bradley 1734-FPD is a field potential distributor module with field side features, and it belongs to the POINT I/O series of products, which are designed to break down power distribution in any industrial setting. This distributor module weighs 0.12 kilograms and measures 76.2 millimeters x 25.4 millimeters x 133.4 millimeters in physical dimensions.

The device can operate using either AC or DC voltage, with an operating voltage range of 10 to 28.8 volts DC and 120 to 240 volts AC. The continuous isolation voltage rating of the 1734-FPD is 50 volts when tested at 2600 volts DC for 60 seconds. The recommended terminal screw torque of this module is 0.6 Nm or 7 lb-in.

For wire size, the device can be used with wires that are 0.25 to 2.5 millimeters or 22 to 14 AWG in size. For safety and optimal performance, it is recommended to use solid or stranded copper wire. The Allen Bradley 1734-FPD comes with one terminal handle and one removable terminal block (RTB) and can be mounted both vertically and horizontally.

This device has a power bus supply current rating of 10 amperes and has an operating temperature range of -20-55 °C. The embedded adapter allows the module to execute communication protocols such as DeviceNet, ControlNet, or Ethernet/IP. Moreover, the 1734-FPD is a field-side voltage distribution module, which is a member of the Allen-Bradley PLC series. It has no power consumption, thermal dissipation, or power dissipation, making it an ideal choice for field power distribution. The device has an open-style enclosure type rating and can be used with open networks using 1734-adapters.
