Description

The Allen-Bradley 25B-D6P0N114 is a PowerFlex 525 adjustable frequency AC drive with a power rating of 2.2 kW or 3.0 HP. It can be mounted on a DIN rail and comes enclosed in a Frame A NEMA open-type enclosure. While it has an IP rating, it is not waterproof and should be protected from corrosive elements by being placed inside a NEMA rated enclosure.

Here are some of the technical specifications of the Allen Bradley AC drive 25B-D6P0N114:

• Output Power Rating: 2.2 kW (3 hp) (Normal and Heavy-duty)
• Output Voltage Rating: 480 VAC, 3 Phase
• Output Current: 6 Amps
• Input Voltage: 380-480V, 3 Phase
• Interface Module: Standard
• Protection Rating: IP20 NEMA / Open Type
• Frame: Size A
• EMC Filtering Options: Filter
• Dimensions: 152 x 72 x 172 mm
• Weight: 1.85 kg

For communication, the 25B-D6P0N114 has one USB port and one Ethernet port. The integrated Human Interface Module (HIM) features advanced options such as Start, Stop, Forward, Reverse, and Jog and a circular dial connected to the built-in potentiometer for modifying the output frequency and motor speed. The HIM also has an LCD readout for monitoring the drive’s status and navigation and confirmation keys for drive configuration.

The 25B-D6P0N114 supports local and remote operation, traditional VFD integration, and modern integration via the embedded Ethernet I/P interface with the Premiere Integration option. Modern integration uses Studio 5000 Logix designer to communicate with a CompactLogix or ControlLogix controller. The drive delivers an output power of 2.2 kW or 3.0 HP for normal and heavy-duty operation, with a motor output current of 6.0 Amperes. It can implement modulating speed using a variety of control methods such as Sinusoidal Pulse Width Modulation (PWM), Volts/Hertz (V/Hz), Sensorless Vector Control (SVC), Economizer SVC motor control, Closed Loop Velocity Vector Control, Surface Mount and Interior Permanent Magnet Motor (without encoder), and Interior Permanent Magnet Motor (with encoder).

This drive has an EMC filter designed to operate in high-temperature environments up to 70 degrees Celsius. It also comes with a Safe Torque feature for added safety. The front panel features a built-in LED, one integrated potentiometer, and dedicated buttons for powering on and off the device. There are also navigational buttons and a jog dial for toggling between different configuration settings.

The installation environment should be free from current and dry during the installation process. The 25B-D6P0N114 has passed various safety, health, and environmental certifications and is an ideal solution for industry standards.
